World's First USB-driven
Touchscreen Monitor

• DisplayLink
  certified
• AUTO PIVOT
• VESA MOUNT
  OPTIONAL
• Mobility
• USB 2.0
• single Touch

Major Features

• USB Input for Power and Video
• Resistive Touchscreen
• Multi-Monitor environment
• 7inch Touchscreen Resolution: 1.024*600
• Vesa 75 Standard
• PC and MAC Compatible

Why do you need the MIMO UM-760RF USB monitor?

Mimo UM-760RF USB monitor is a “VESA 75 MOUNTABLE” Model
UM-760RF is a VESA 75 standard compatible touchscreen monitor that easily mounts to wall brackets, telescoping arms,
desktop displays,
even auto seats and windshields/windscreens, PLUS the same great touchscreen functionality as the 760R. All power
and data provided by a single USB cord.

Multi-Monitor Environment, Productivity improvement

Adding a second or extended monitor to your computer increases your productivity and makes your work day easier by
10 ~ 50%, that is multiple monitor solutions are giving us a productivity solution simply connecting MIMO USB monitor via
just USB port utilizing USB for both power and video input.
No additional hardware such as video port, video cable or power adapter required.

Supports a variety of Applications as a second monitor

● Increasing Productivity while using other main screen

- Monitoring Outlook/Mail, viewing and editing word file

● Multi-Media Player to control entertainment

- Watching Movies and Internet Video
- Quick access to toolboxes for online gaming
- Viewing Digital Photo Albums (PC based)

● Messenger for Social Relationship

- Instant Messenger, Internet Phone Applications
- Skype, MSN, Google Chatting
- Access to Facebook and MySpace to watch for friends
- Keep your Twitter Client up all the time.

● Widget Station

- Stock monitoring, Time, Weather, Memo, Viewing Calendars, exchanging rate, google news

Specification

	Specification	TSP Model
Display	Screen Size	7.0”Wide
	Resolution	WSVGA(1,024*600)
	Display Colors	16.7M
	Brightness	250cd/mm
	Contrast Ratio	700:1
	Response Time	10msec
Signal Input	Touch Input	Resistive Touch Screen Panel
	Video Input	USB 2.0
	Connector	USB Mini B
Power	Power Input	USB Power (tV, 500mA)
	Power Consumption	2.0 ~ 4.5W
Feature	UI.Pivot	Pivot (Landscape, Portrait)
Dimensions	Product Dimension (opened)	185(W) x 145(L) x 120(H)
	Product Dimension (folded)	216(W) x 184(L) x 63(H)mm
	Shipment Dimension

PC System Requirements

▶ PC H/W Requirements

- CPU : Intel Pentium / Celeron / AMD / K6 / Athlon / Duron 1.2GH or above

- RAM : 512MB or above

- USB : at least one or more USB 2.0 port

- 30MB HDD space above

▶ Operating System

- Window 8(64bit), Windows 8(32bit), Window 7(64bit), Windows 7(32bit)

- MAC OSX

- Snow Leopard(32bit only), Leopard 10.5.6, Tiger 10.4.11
